| Power Supply |
|
| Power supply voltage |
11 ÷ 15 VDC |
| Idling current |
0.4 A |
| Switched off |
|
| Remote IN voltage |
7÷15 VDC (1 mA) |
| Remote OUT voltage |
11÷15 VDC (15 mA) |
| Internal fuse (AFS) |
15 A |
| Consumption @ 14.4 VDC, 2Ω, Max Musical Power |
11 A |
| |
|
| Amplifier stage |
|
| Distortion - THD (1 kHz @ 4Ω) |
0.07% |
| Bandwidth (-3 dB) |
15 ÷ 50 kHz |
| S/N Ratio (A weighted @ 1 V) |
100 dB |
| Damping factor (1 kHz@ 4Ω) |
200 |
| Input sensitivity (PRE IN) |
0.3 ÷ 5 VRMS |
| Input sensitivity (Speaker IN) |
1 ÷ 15 VRMS |
| Input impedance (PRE IN) |
15 kΩ |
| Input impedance (Speaker IN) |
100 Ω |
Load impedance (Min)
2 Ch
1 Ch |
2Ω
4Ω |
| |
|
| CEA 2006-A RATINGS |
 |
| RMS Power (4 Ohms, ≤1% THD+N, 14.4 Volts): 60W x 2 Ch |
| S/N Ratio (ref. 1W output): 83 dBA |
| |
|
| OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%: |
| 2 Ch |
60W x 2 (4Ω) |
| 2 Ch |
90W x 2 (2Ω) |
| 1 Ch |
180W x 1 (4Ω) |
| |
|
| Inputs/Filters |
|
| Input |
PRE IN / Speaker IN |
| Stereo Filters Full / Hi-pass |
50 ÷ 5k Hz @ 12dB/Oct. |
| Mono Filters Full / Hi-pass |
50 ÷ 5k Hz @ 12dB/Oct. |
| |
|
| Dimensions |
|
| Max size (mm) |
213 x 53.5 x 408 |
| Weight (kg) |
2.4 |
